MHD2

BASIC

E35MHD2014001
E35MHD2041001
european homologation

Manure spreaders / muck spreaders agricultural trailers Juscafresa for fruit trees.
Destined for small and medium agriculture works / farms of fruit trees such as olive trees, avocado trees, apple trees and others.

Stands out for its excellent spread quality between fruit trees and vineyard.

Standard equipped with:
Drag system 2 chains 80/12 C 10 + S 275 JR
Double horizontal beater with welded spades and with 2 lower discs
Hydraulic back cover compass type guided with synthetic belt for the closing hydraulic back cover
Fixed removable manure locator cover
Upper frontal protective grille
Fixed drawbar with adjustable height


Capacity: 4,14 - 4,80m3

MODELS

E35MHD2

E40MHD2

4,14m3

4,80m3

Dimensiones
mhd2 v
mhd2 f
E35MHD2014
E40MHD2014
E35MHD2041
E40MHD2041
m3
4,14
4,8
4,14
4,8
A
5652
6152
5652
6152
B
4389
4889
4389
4889
C
2074
2074
2240
2240
D
1500
1500
1900
1900
E
1697
1797
1697
1797
F
745
745
690
690
G
1905
1905
1862
1862
H
402
402
465
465
J
2142
2142
2090
2090
K
3955
4355
3955
4355
U
3218
3718
3218
3718
X
1530
1530
1530
1530
wheel
860
860
845
845

Descriptions, data and illustrations are only indicative. Juscafresa reserves the right to make any changes without prior notification.

work mhd2014

MHD2014

The MHD2014 models have a maximum width of 2074mm and height of 2142mm ideal for spread between vineyards where we need less widthfor narrow paths. The wheels are integrated below the spreader box to gain less width.

SEE MPD2 and MDD2 SERIES for smaller widths.

work mhd2041

MHD2041

The MHD2041 models have a maximum width of 2240mm and height of 2090mm ideal for spread between fruit trees where we need less high for more wider paths but full of branches where we must gain height. The wheels are next to the spreader box to gain lower height.

SEE LMH2 SERIES for more capacity.

Características

Spreader system

Double horizontal beaters with screwing flat spikes and with 2 lower discs.



The lower plates are protected by plates in order to avoid the material fall directly to the floor and ensuring it is spread through the back without falling below the machine and getting it dirty.

Optional:

Reduction double horizontal beaters with screwing flat spikes.

Adjustable and dismountable manure direction system, central direction.

Adjustable and dismountable manure direction system, side direction to both sides.

Adjustable and dismountable manure direction system, side direction in line and to both sides special for vineyard.

mhd2

Material steel

4mm side thickness of standard and floor thickness of 3mm.

Drive shaft Bondioli & Pavesi

Security screw of standard or homokinetic joint optional front transmission and overrunning clutch and back transmission with standard.


Drag system

Kit of 2 or 4 chains 80/12 manufactured with material C10 + S275 JR.

Manual independents tensors.

Reducer

Hydraulic advance chains with reducer 1/8,15.

reductor 8,15
distribuidor manual

Velocity commandment from the chains

Manual velocity commandment from the chains floor.

Spreader system standard

Hydraulic back cover compass type guided with synthetic belt for closing, double horizontal beaters with screwing flat spikes and with 2 lower discs and fixed removable manure locator cover.

puerta

Spreader system optional

Reduction double horizontal beaters with screwing flat spikes.

Adjustable and dismountable manure direction system, central direction.

Adjustable and dismountable manure direction system, side direction to both sides.

Adjustable and dismountable manure direction system, side direction in line and to both sides.

puerta

Spreader system optional

Manure locator cover with hydraulic opening.

puerta

Drawbar and jack-stand

Fixed drawbar height adjustable of standard or mobil drawbar with hydraulic cylinder optional.

lanza fija
lanza movil

Axle



Available in models E35MHD2014 and E40MHD2014.

Square straight axle 70 mm, 1500 track, 6 bolts, without brakes.

Available in models E35MHD2041 and E40MHD2041.

Square straight axle 70 mm, 1900 track, 6 bolts, without brakes.

050

Optional wheels

E35MHD2014
E40MHD2014
E35MHD2041
E40MHD2041
10.0/75 - 15.3
O
-
-
-
11.5/80 - 15.3
-
O
O
O

“A higher quality finish means more machine life”

The Juscafresa finishing process is:

-Polishing of the whole machine removing the impurities that persist in the metal.



-Pressurized washing with degreaser solution to obtain a better grip on the primer and prevent corrosion.



-Wash at high pressure with hot water to remove dirt from the metal and remains of adhered products.



-Application of a high quality primer layer.



-Application of two layers of Juscafresa paint specially designed with our corporate color.

acabado metal juscafresa

Descriptions, data and illustrations are only indicative. Juscafresa reserves the right to make any changes without prior notification.
